CFI Oil Separators
Australian designed and manufactured, the Mascot CFI unit is one of the most efficient on the market. Units can be supplied in two standard models and are capable of reducing the oil content in the effluent to less than 10 parts per million:
Depending on the pump chosen, our CFI works as up to 1500L per hour and up to 3000L per hour.
Wash-Down and Pump-Out Pits are also available in our unique Glass Reinforced Concrete (GRC) for easy installation.
Cross flow units
| No. | Product Code | Description |
|---|---|---|
| 1 | CFI | 1500L or 3000L Unit |
Above CFI Units come complete with CFI Unit, Plate Pack, Stand and Covers.
Pumps
| No. | Product Code | Description |
|---|---|---|
| 2 | CFICP25 | Pump for CFI15 |
| 2 | CFICP800 | Pump for CFI30 |
| No. | Product Code | Description |
|---|---|---|
| 2 | CFI15ASM | Diaphragm Pump for 1500L |
| 2 | CFI30ASM | Diaphragm Pump for 3000L |
Above pumps are progressive cavity 240 Volt (Non flame proof). 415 Volt and flame proof options are available. Please confirm with your local water authority if a Diaphragm or Progressive Cavity Pump is required.
Accessories
| No. | Product Code | Description |
|---|---|---|
| 3 | CFICP | Control Panel |
| 4 | CFIBA | Bell Alarm |
| 5 | CFIF6 | Float Switch (1 only) |
| 6 | CFIFV15 | Flap Valve for 1500L |
| 6 | CFIFV30 | Flap Vale for 3000L |
Wash down and pump-out pits are also available in our unique Glass Reinforced Concrete GRC for easy installation
